GIOTTO: UPS 450 – 2000 VA 1/1
Compact UPS
450-2000 VA Line-interactive 1-phase
Line-interactive (VI) 1-phase UPS, ideal for home and small office PC, CCTV and security systems. Ensures your systems availability, protects your equipments and peripherals from power failures causing data loss and hardware damage.
- User-friendly, plug and play, ready to use
- Compact and noiseless, can be placed anywhere
- Energy efficient, ensuring low energy costs and environmental impact
- Free downloadable software
Benefits:
- Automatic Voltage Regulator (AVR)
- Automatic start
- Auto shut down in the event of a mains fail
- Smart LED Display
- User-replaceable battery
- Filtered socket protection against overvoltage for LAN/ADSL
- USB port for direct PC connection
- Borri Power Guardian, user-friendly UPS management software free downloadable at www.borri.it/support. Borri Power Guardian is available for MAC, Microsoft and Linux operating systems, providing UPS management, safe system shutdown during blackout or other computer failure and remote diagnostics of main settings.
Features:
- Line-interactive UPS with VI technology
- AVR technology (Automatic Voltage Regulation)
- Full compliance with international product standards
- Cold start function. The UPS can be started from battery when AC utility is not available
- USB and RJ-11/45 ports
- One output receptacle IEC 320-C13 and one Schuko for models from 450 to 850 VA
- Four output receptacles IEC 320-C13 and one Schuko for models from 1000 to 2000 VA
Gallery
Technical Specifications
GIOTTO 450-2000 VA Line-interactive 1-phase technical data
| Rating (VA) | 450 | 650 | 850 | 1000 | 1500 | 2000 |
| Nominal power (W) | 270 | 380 | 500 | 600 | 900 | 1200 |
| UPS dimensions WxDxH (mm) | 100x292x140 | 148x315x198 | ||||
| UPS weight (kg) | 4 | 5 | 5.5 | 9 | 10.5 | 11.8 |
Input
| Connection type | 1 IEC 320-C14 |
| Nominal voltage | 230 Vac |
| Voltage range | 160÷290 Vac |
| Frequency and range | 50/60 Hz, 45÷65 Hz |
Output
| Connection type | 1 IEC 320-C13 and 1 Schuko | 4 IEC 320-C13 and 1 Schuko |
| Nominal voltage | 230 Vac single phase | |
| Frequency | 50/60 Hz | |
| Waveform | Simulated sine wave | |
Battery
| Autonomy time (min)* | 50% load | 8 | 10 | 11 | 13 | 8 | 9 |
| 100% load | 3 | 3 | 3 | 3 | 3 | 3 |
* Measurement conditions: optimised parameters, battery full charged, Power Factor (PF) 0.6
Connectivity and function extensions
| Front panel | LCD, ON/OFF button |
| Communication | Included: USB. Compatible platforms: Microsoft Windows, Linux, Mac |
Environmental
| Operating temperature range | 0°C ÷ +40°C |
| Altitude (AMSL) | < 1000 m without power reduction, > 1000 with reduction of 0.5% per 100 m |
| Audible noise at 1m (dBA) | <50 |
| Relative humidity | 0-95% |
Standards and certi cations
| Marking | CE |
| Safety | IEC EN 62040-1 |
| EMC | IEC EN 62040-2 |
| Quality assurance, Environment, Health and Safety | ISO 9001:2008, ISO 14001:2004, BS OHSAS 18001:2007 |
